Features:
¡ö Low cost , Small size
¡ö Proven long term Stability and Reliability
¡ö High Sensitivity and Fast thermal response
¡ö High
accuracy and Interchangeability, Thermally Conductive Epoxy coated
Applications:
¡ö Temperature sensing , control and compensation
¡ö Automotive car seat heater control and engine management
¡ö P.C. board mounting for over temperature protection
¡ö General Instrumentation applications
XX — ¢Ù |
MF — ¢Ú |
5A-5 —— ¢Û |
-327 — ¢Ü |
-502 — ¢Ý |
F — ¢Þ |
Notes£º
¢Ù XIXI Co.
¢Ú NTC thermistor
¢Û Epoxy coated type modle 5A-5
¢Ü B value£¨B25/50¡æ£© Example: 327-- B 25/50¡æ: 3270
¢Ý Standard resistance value at 25¡æ£¨R25¡æ£©,Example£º502. R25¡æ is 5KΩ
¢Þ R25¡æ interchangeability precision£º
F£¨±1%£©£»G£¨±2%£©£»H£¨±3%£©£»J£¨±5%£©£»K£¨±10%£©
specification |
R25¡æ £¨KΩ£© |
B25/50¡æ £¨K£© |
disspation constant £¨mW/¡æ£© |
time constant £¨S£© |
operation temperature range
£¨¡æ£© |
XXMF5A-5 -347-202¡õ |
2 |
3470 | 0.75-3.0 typical in still air at 25¡æ |
1-1.5 typical in liquids |
-30¡«125 |
XXMF5A-5 -327-347-502¡õ |
5 |
3270/3470 | |||
XXMF5A-5-347/390/395-103¡õ |
10 |
3470/3900/3950 | |||
XXMF5A-5-395-473¡õ |
47 |
3950 | |||
XXMF5A-5-395/400-503¡õ |
50 |
3950/4000 | |||
XXMF5A-5-405/420-104¡õ |
100 |
4050/4200 | |||
Note 2) We will produce suitable temperature sensors according to the technical details you provide such as dimension, operating temperature, thermal time constant, precision, etc.
